应用范围/Applications：
主要生产碳纤维自行车配件、碳纤维零钱包、碳纤维假肢假脚、碳纤维直升机、碳纤维运动器等各种碳纤维制品、玻璃纤维制品。
It mainly produces carbon fiber bicycle accessories, carbon fiber automobile parts, carbon fiber wallet, carbon fiber artificial limb, carbon fiber UAV, carbon fiber sportswear and other carbon fiber products, glass fiber products.
特点/Characteristics：
一、可配机械自动开模，方便人员操作；
二、采用比压比流或伺服油路设计，稳定、节能，上升下降速度可因使用需求调整；
三、具有慢速校模功能，校模更精确、更安全。
1、It can be equipped with mechanical automatic mould opening, which is convenient for workers to operate.
2、Adopting specific pressure specific flow or servo oil circuit design, which is stable and energy-saving;increase in the rate of decline may be due to the use of demand adjustment;
3、 Slow moving speed is available for alignment safer and more accurate.
技术参数/Technical parameters:
| 型号Type | MH-400 | MH-500 | MH-600 | MH-800 | MH-1100 | MH-1500 |
| 面板尺寸Heating plate size (mm) | 400*400 | 500*500 | 600*600 | 800*800 | 1100*1100 | 1500*1500 |
| 合模力Clamping Force (T) | 50T-200T | 100T-500T | 100T-500T | 100T-500T | 150T-500T | 150T-500T |
| 行程Stroke (mm) | 250-300 | 250-300 | 250-300 | 250-300 | 250-300 | 250-300 |
| 功率Power (KW) | 2.2 | 3.75 | 5.5 | 5.5 | 5.5 | 5.5 |
| 控制系统Control System | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI | PLC+HMI |
| 工位Workstation (QTY) | 1-3站可定制 | 单站 | ||||
| 备注Remarks | 面板尺寸可定做 | |||||
*如有参数变更，恕不另行通知。We reserve the right to change any design and specification without ontice.
